Vivid 4 is a modular video panel vividly displays content without the need of bulky media servers. Create dazzling video displays with these lightweight video panels that feature Black body LEDs that accurately reproduce high-contrast videos. Vivid 4 makes a perfect DJ façade and seamlessly integrates with Serato for displaying music videos to add gig excitement. Set up is easy and fast with multiple magnets and positioning pins that make getting up and running tool-free and effortless. Stellar reliability and quality are built into Vivid 4. Dual power supplies ensure downstream panels don’t lose signal. Intelligent modules with dedicated memory improve the image quality and simplify maintenance. Panels can be suspended vertically or horizontally offering different aspect ratio options. Multiple Speego connectors mean Vivid 4 sets up twice as fast as other panels.


Specifications


Light Source: 21,632 SMD 2020 LEDs (tri-color RGB) 0.3 W, (60 mA), 50,000 hours life expectancy

Power Linking: 7 units @ 120 V; 13 units @ 230 V

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

Power and Current: 280 W, 2.3 A @ 120 V, 60 Hz
280 W, 1.2 A @ 230 V, 50 Hz

Weight: 27.6 lb (12.5 kg)

Size: 19.7 x 1.9 x 39.4 in (500 x 65 x 1000 mm)

Approvals: CE, MET

Wavelength: 620 to 625 nm red, 516 to 530 nm green, 460 to 475 nm blue

Viewing Angle: 120°

Maximum Illuminance: 1,200 NITS

Calibrated Illuminance: 1,000 NITS

Contrast Ratio: 4,300:1

Refresh Rate: 1,920 Hz

Pixel Density: 43,264 m2 (104 x 208)

Pixel Pitch: 4.8 mm

Minimum Viewing Distance: 12 ft (4 m)

Maximum Vertical Hang: 23 panels

Maximum Horizontal Hang: 17 panels

Required Controllers: Vivid Drive 23N

Optional Mounting Brackets: RB-F50CM, RB-F100CM








WHAT'S INCLUDED



(x4) Vivid 4

(x1) Road case

(x1) Seetronic Powerkon power cord

(x4) Seetronic Powerkon power linking cords

(x4) Seetronic EtherCon signal linking cords

Warranty card

User Manual
